Product Description
| Model | Length(mm) | Power | Input
Voltage
|
LED type | LED
Q'ty(pcs)
|
CRI | Luminious | Beam
Angle
|
| DP-IT5C4-C40E0M3-C | 288±1mm | 4w | AC90-264V
|
SMD2835 | 40 | ≧80 | 540lm | 120-140° |
| DP-IT5C8-C80E0M6-C | 549±1mm | 8w | SMD2835 | 80 | 1080lm | |||
| DP-IT5C12-C120E0M9-C | 849±1mm | 12w | SMD2835 | 120 | 1620lm | |||
| DP-IT5C18-C168E1M2-C | 1149±1mm | 18w | SMD2835 | 168 | 2340lm | |||
| DP-IT5C18-C216E1M5-C | 1449±1mm | 18w | SMD2835 | 216 | 2430lm | |||
| CCT Range: WW:3000K; NW:4000K; PW:5000K; CW:6000K PF>0.95 | ||||||||
● Exclusive internal driver design in such small T5 tube, install very simply and directly connect to 90-264VAC. Very
competitive and popular in Europe and the USA market.
● High efficacy 120-130LM/W for whole lamp, save 80% energy. LM-80 approved SMD2835, lifes(L70) 50,000-80,000 hrs.
● High quality 6063# aluminum body ensure tube excellent heat dissipation, temperature rise<20℃, greatly expand tube
lifespan.
● Strong PC cover, delicate, not bending and deformation, perfect choice to replace T5 fluorescent tube.
● No flash, No glare, very stable and comfortable light, protect eyes.
● 3 year warranty, real top quality. Twice as life as common external driver T5 led tube from other suppliers.
Application:
* Residential Buildings, Meeting Room, Show Room, Museum, Art Gallery, Hotels, Hospitals, Schools, Parking Lots, Subways
* Factories / Warehouses / Offices, Super-markets, Shopping Mall, etc.
